11 KUPO

XLR Water-proof Cover Black Jelly Sleeve
XLR-WPC [XLR WATER PROOF COVER] XLR-BJS [ BLACK JELLY SLEEVE]
XLR-WPC is designed to protect XLR connector from wet and dust. XLR-BJS is silicon made sleeve for XLR cables with superior protection,
See-through transparent PVC body helps check up mating status easily. especially for those ready-made cables without protection on connector in
Feasible for O.D.4-6 mm cable. IP66. advance. With this elastic black silicon sleeve, the ordinary cable is
prompted with additional shield. IP65 while mated and feasible for 3pin
and 5pin XLR.

Powerlead
Powerlead is 20A/250Vac rated single phase AC power connector, featuring twist-and-lock engagement with greatest
security. It is UL listed and made with high standard to ful ll the rigorous criteria in the entertainment industry. Ideal for LED
xture as power source. POWERLEAD is compatible with major brand of the likes.

Features
≫ Non-interchangeable and color-coded,
ensuring mistake-proof connection system.
Blue for power-in, and grey for power-out .
≫ Contact with one micro silver-plated for
excellent electric conductivity.
≫ Metal ange on the slot xity to avoid any
fray.
≫ Reinforced thermoplastic forms the
housing for the robust and maximum
durability, and UL94V-HB ame-retardant
meets safety requirements.
≫ Ergonomic latch for handy use with less e
ort and ensure the firm lock .
Electrical Contact resistance: ≤ 3 m Ω / Dielectric strength: 4 kVdc / ≫ T-type thread on inner side of rear cap
Insulation resistance: > 0.1 G Ω (after damp heat test IEC 68-2-30) / Rated enhance the rotary tightened for slip free.
current per contact: 20 A / Rated voltage: 250 V ≫ Hexagonal-shaped rear cap for operation
Material Bushing: Polyamide (PA 6 15% GR) / Contact plating: 4 μm Ag / with bare hand or a wrench; rubber
Contacts: Bronze (CuSn6) Insert: Polyamide (PA 6 30 % GR) / Locking bushing ts wide range of cable and
element: Zinc diecast (ZnAl4Cu1) / Shell: Polyamide (PA 6 30 % GR) / Strain relief: POM provides outstanding environment
Mechanical Cable O.D.: 5 - 15 mm Lifetime: > 1000 mating cycles Wire size: 2.5 mmsq / 14 AWG protection.
Environmental Solderability: Complies with IEC 68-2-20 Temperature range: -30 °C to +80 °C ≫UL listed.

PDB-11JB Power Junction Box
The robust chassis is fabricated with high tensile aluminum
extrusion with black anodized nish. Mylar lm completely wraps
around the inner soldering area for best insulation.
Soldered with 2.5mm silicon wire secures higher working current
capacity. Assembled with 20A lockable socket, and compatible with
original Neutrik Powercon connectors.
