Soft Profile F zoom Max Soft Profile PC zoom Min Soft Profile PC zoom Max

■1/2 peak angle : 26° ■1/2 peak angle : 14° ■1/2 peak angle : 23°
■1/10 peak angle : 43° ■1/10 peak angle : 23° ■1/10 peak angle : 39°

Reflection LEDko T
VariWhite Series 2

KEY FEATURES
≫ 2.700 K - 6.500 K Con nuously Variable Correlated Color Temperature with
color rendering index greater than 95 (CRI>95)
≫ An innova ve “Mul -LED” light source producing a uniformed beam with no low power
pixels or dots (Patented) consumption
≫Superior flat field optics Reflection LEDko
≫Also compa ble with new Fresnel and PC op cs with shu ers (So Profile) reduces power
≫Guaranteed Flicker-free opera on (DMX controlled PWM frequency) consumption levels by
≫PowerCon In/Out, up to 8 fixtures powered in series for easy installations up to75% and
≫The fan settng allows two options : Auto, Silent therefore recoverign
≫Instant gobos from standard printers the financial investment
≫No maintenance required within a few month.

Reflection LEDko VariWhite Series 2
SPECIFICATIONS
Propor onal control of white color temperature from 2.700 to 6.500 K
Four blade framing system, each shu er blade is adjustable for
radial posi on and angle
Electronic 16 bit dimming with 3 selectable curves (exponen al,
logarithmic, linear)
Synchronized, random or pulse electronic strobe
Flicker-free opera on with LEDs frequency controlled via DMX from
600 Hz to 19000 Hz
Fan se ng with 2 di erent op ons (Auto, Silent)
CE, ETL, UL approved
Weatherproof ra ng IP 20
PHYSICAL SIZE (With optic Soft Profile Fresnel) Modular 210 W mul ple LEDs , CRI>95
Length 601 mm (23.6 in) 20,000-hour LED life (20,000 hours to 70% intensity)
Width 212 mm (8.3 in) CONTROL PROTOCOL AND PROGRAMMING
Height 189 mm (7.4 in) USITT DMX512A
Height with bracket 372 mm (14.6 in) DMX channel 5/1
Weight 8.5 Kg (18.7 lbs) Se ng, addressing, tes ng and measurements via LEDs display
PHYSICAL SIZE (Without optic) Remote Device Management (RDM)
Length 362 mm (14.2 in) ELECTRICAL SPECIFICATIONS/CONNECTIONS
Width 212 mm (8.3 in) AC power 90-230V, auto sensing, 50/60 Hz
Height 189 mm (7.4 in) In and Out PowerCon connectors to feed up to 8 (at 230 VAC) or 4
Height with bracket 372 mm (14.6 in) (90 VAC)
Weight 6 kg (13.2 lbs) Power consumotion 1Aat230V,2.6Aat90V-cosφ0,9
LIGHT SOURCE DMX data in/out 5 pin locking XLR
