06 COEMAR

Reflection LEDko T low power consumption
CRI 90 Reflection LEDko reduces
power consumption levels by
up to75% and therefore
recoverign the financial
investment within a few month.

KEY FEATURES Reflection LEDko T - CRI 90
≫CRI 90 SPECIFICATIONS
≫Light source: 200W Tungsten LEDs Fixed white color temperature 3200 K
≫Soft profiling thanks to Fresnel and PC optics(Coemar patent) Four blade framing system, each shu er blade is adjustable for radial
≫Smooth 16 bit dimmer posi on and angle
≫ Guaranteed Flicker-free operation (DMX controlled PWM Electronic 16 bit dimming with 2 selectable curves, simula ng halogen
or discharge lamp based xtures
frequency) Synchronized, random or pulse electronic strobe
≫ Adjustable fan setting allowing low noise operations, auto- Flicker-free opera on with LEDs frequency controlled via DMX from 600
silent, DMX, maximum speed Hz to 19000 Hz
≫Instant gobos from standard printers Fan se ng with 4 di erent op ons (low-noise, auto-silent, DMX,
maximum speed)
CE, ETL, UL approved
Weatherproof rating IP 20
PHYSICAL SIZE (With optic Soft Profile Fresnel)
Length 601 mm (23.6 in)
Width 212 mm (8.3 in)
Height 189 mm (7.4 in)
Height with bracket 372 mm (14.6 in)
Weight 8 Kg (17.6 lbs)
Reflection PHYSICAL SIZE (Without optic)
LEDKo White 362 mm (14.2 in)
Body Length
Width 212 mm (8.3 in)
Height 189 mm (7.4 in)
Height with bracket 372 mm (14.6 in)
Weight 5.5 kg (12.1 lbs)
LIGHT SOURCE
Modular 200 W COB LED, CRI 90, TLCI 88
LEDs life 20.000 hours at 70% lumen intensity maintenance
CONTROL PROTOCOL AND PROGRAMMING
Reflection USITT DMX512A
LEDko
without optic DMX channel 5/1
Se ng, addressing, tes ng and measurements via LEDs display
RDM
ELECTRICAL SPECIFICATIONS/CONNECTIONS
AC power 90-230V, auto sensing, 50/60 Hz
In and Out PowerCon connectors to feed up to 8 (at 230 VAC) or 4 (90 VAC)
Power consumotion 1.2Aat230V,3Aat90V-cosφ0,9
DMX data in/out 5 pin locking XLR
ACCESSORIES
Gobo holder
Colour frame
Iris
Reflection 4-leaf barndoor
LEDko Rear Flight case
panel
Optics Profile/Soft Profile, various angles available

Reflection LEDko T - CRI90 - Optics

Code Description Code Description Code Description Code Description
BC10011A017 Profile Zoom 15°-35° BC10011A019 Profile Zoom 25°-50° BC10011A003 Profile Zoom 28°-40° Soft Profile Fresnel
BC10011A002 Zoom 14°- 40°

200
