04 DESISTI

DEB DIGITAL ELECTRONIC BALLASTS
DIGITAL DEB 2,5-4 KW MOD. 2535
≫Protection for high or low input voltage: Avoids ballast breakage in case
of wrong mains connection (for instance 380V)
≫Power factor correction (active line filter)
≫ 16 Digit LED display: It include a membrane keypad in order to activate
different functions, Multi-language menu, System diagnostic, DMX
addressing, DATA LOG (hour counter for lamp/ballast operation, record of
diagnostic status). Output Frequency set up (for high speed electronic
shutter in PAL or NTSC)
≫Local, Remote and DMX Control ≫Low noise & flicker free selector
≫Self adjusting cooling system
≫Dual Power output with automatic selection
≫Output short circuit & arc to ground protection
≫Constant output lamp power ≫Quartz generated output frequency

ELECTRICAL PERFORMANCES WEIGHTS & DIMENSIONS
95-135 V
Input Voltage dimensions inches mm
185-265 V Width (A) 10.63 270
38 A (4kw) – 23-5 A (2.5 kw) at 110 V 12.6 320
Nominal effective input Height (B)
current 20 A (4kw) – 12.5 A (2.5 kw) at 220 V Depth(C) 14.76 374
Efficiency (Average) > 0.93 weight lbs kg
Power Factor (Average) > 0.95 48.4 21.95
Dimmer Range 30% Working Position Ballast with control panel facing front
On/Off Control Local Remote or DMX Ambient Temperature - 20...+45° C
& umiditiy allowed IP23

DIGITAL DEB 1,2-2,5 KW MOD. 2525
≫ (in case the lighting fixture is intended for use with the 2500W lamp only)
≫ Protection for high or low input voltage: Avoids ballast breakage in case
of wrong mains connection(for instance 380V)
≫Power factor correction (active line filter)
≫ 16 Digit LED display: It include a membrane keypad in order to activate
different functions, Multi- language menu, System diagnostic, DMX
addressing, DATA LOG (hour counter for lamp/ballast operation, record of
diagnostic status). Output Frequency set up (for high speed electronic
shutter in PAL or NTSC)
≫Local, Remote and DMX control ≫Low noise & flicker free selector
≫Self adjusting cooling system
≫Dual Power output with automatic selection
≫Output short circuit & arc to ground protection
≫Constant output lamp power ≫Quartz generated output frequency

ELECTRICAL PERFORMANCES WEIGHTS & DIMENSIONS
Input Voltage 95-135 V dimensions inches mm
Nominal effective input 12.5 A (1.2kw) – 26 A (2.5 kw) at 110 V Width (A) 10.63 270
current 6.20 A (1.2 kw) – 13 A (2.5 kw) at 220 V Height (B) 10.63 270
Efficiency (Average) > 0.93 Depth(C) 14.76 374
Power Factor (Average) > 0.95 weight lbs kg
Dimmer Range 30% 48.4 21.95
On/Off Control Local Remote or DMX Working Position Ballast with control panel facing front
Ambient Temperature - 20...+45° C
& umiditiy allowed IP23
