11 KUPO

ALUMINUM MINI ALUMINUM
EXTRUSION CLAMP EXTRUSION CLAMP
C-08 Silver / C-08B Black C-09 Silver / C-09B Black
Weight 0.38kg Weight 0.09kg
Safe Working Load 275kg Safe Working Load 55kg
Bolt 1/2”-13 Bolt 5/16”-18

The C-08 clamp is made from high tensile extruded C-09 clamp is same profile as C-08 but with miniature
aluminum. It is light weight and strong hanging hardware size. It is ideal for hanging fixture like Par16 birdie or LED
for conventional fixture. The interior teeth of clamp are fixture on to a tube from 1” to 1-1/4” tube. with 5/16”-18
designed to grip the tube from 1-1/4” to 2” tube. With yoke bolt and washer.
1/2”-13 yoke bolt and washer. Black Anodized finish.

ALUMINUM ALLOY HOOK CLAMP QUICK RELEASE ALUMINUM ALLOY HOOK CLAMP
C-05 Silver / C-05B Black C-05QP Silver
Weight 0.45kg Weight 0.48kg
Safe Working Load 40kg Safe Working Load 40kg
Bolt 3/8”-16 Bolt 3/8”-16
Light weight aluminum die casting hook clamp comes with The same as C-05 hook clamp but with a spring
a dia.17mm spigot (Dabo) with 3/8”-16 bolt for fixture release collar to lock spigot automatically and push to
yoke. Intend for rigging Par can and lightweight fixtures. A release quickly.
wing bolt allows no tool loosen to do pan adjustment quick
and safely. The pipe bolt is built with truss protector to
avoid possible truss damage. It is designed for finger tight
only and overhanging is not suggested.

Same features with C-05 clamp but made with iron casting material for heavier duty and durability. Fit tube diameter
30-51mm. Standard finish in black. C-01QP comes with quick locking latch for holding the spigot (DABO) automatically and
releaseing without too much effort.

STEEL IRON CASTING CLAMP STEEL IRON CASTING CLAMP
C-01 Black C-01QB Black
Weight 0.64kg Weight 0.64kg
Safe Working Load 40kg Safe Working Load 40kg
Bolt 3/8"-16 Bolt 3/8"-16

330
