GIGACORE 26I

The GigaCore 26i is a Gigabit Ethernet switch providing a budget
friendly solution when port density matters. The unit comes with all
the advanced funtionalities of the GigaCore Ethernet switches
range, in a fully AV-installation oriented package. The unit o ers 26
Gigabit ports that are all connected on the front panel. Each port on
the switch will have coloured mode led indications which will
indicate di erent properties of the port such as: PoE, redundancy
and group membership. Con guration can be done trough an
intuitive web interface. The complete GigaCore range is validated
for di erent pro audio and lighting protocols by di erent key
manufacturers and referred as the preferred network solution. This
makes the GigaCore 26i the ideal solution to create a complete
network in Studios, theaters, convention centers...

Features
≫Wire-speed Layer 2/3 managed switch
≫Industry speci c web interface
≫24 x Gigabit copper ports on RJ45
RLINKX ≫4 x Gigabit compliant shared SFP cages
≫2 additional Gigabit compliant SFP cages
The GigaCore managed switches comes by default with RLinkX ≫4 status LEDs for the device: OK, PoE, RLinkX, Power
enabled on every Ethernet port. ≫ Coloured Mode LED per port: PoE, redundancy and
RlinkX stands for Redundant Link by LumineX. This redundancy groupmembership
protocol, based on Rapid Spanning Tree, is tailored to o er users a true ≫Additional LED per port: Link/Speed
transparent and hassle free recovery system in case of link failure. ≫Group : See description on page 24
User simply needs to connect two or more GigaCore switches ≫RLinkX : See description on page 28 ≫Redundant fans
together, to create redundant link(s), no con guration required. In the ≫ Tailored for industry protocols, such as: AES67, ArtNet,
unlikely event of a link failure, switches will automatically activate the
backup link(s). DanteTM, EthersoundTM, MANet 1&2, Q-LAN, REACTM, sACN,
This will result in a seamless data ow within the network, providing and many more...
user a true peace of mind, even in worst case scenario. ≫Pro le Manager ≫IEEE 1588 PTP V2

Options
≫ PoE+ supply unit: Deliver up to 350W through the 20 front RJ45
connectors
≫Redundant Power and PoE supply

PoE - PoE +
PoE allows the user to pass electrical power and data
through Ethernet cabling. For example to provide data
connection and power to devices such as Ethernet-
DMX converters, intercom systems, IP cameras...
All Luminex switches have optional PoE+ and can
deliver up to 150 Watts. Our GigaCore 26i comes with
a total Power over Ethernet budget of 350 Watts
through 24 front connectors.
All Luminex Ethernet-DMX Truss converters come with
standard PoE input meaning it can be powered by a
PoE switch.
