03 LUMINEX

ETHERNET DMX4 TRUSS MKII

The Ethernet - DMX4 / Truss MkII is the “Truss” edition of the Ethernet -
DMX4 MkII. Equipped with one M10 insert for truss mounting, and tted Features
with a rugged enclosure that allows to use the device for wall or truss ≫4 x bi-directionnal DMX connector (Input / Output)
mounted applications. The unit serves 2 Ethercon connectors for an ≫2 x 10/100BaseTX Ethernet port
easy network connection. The Ethernet DMX4 Truss MkII is the perfect ≫Optic and galvanic isolated outputs.
bridge for middle size installations or tours.
≫Shielded connectors
Functions ≫Front end display for quick con guration
≫Converter (Ethernet<>DMX, Ethernet<>Ethernet) ≫ The unit can be powered either through PoE (802.3af ) or mains
≫DMX Splitter, Ethernet & DMX merger - RDM Gateway (create a backup for your power source)
≫ DMX trigger (remote selection of the control source, fade between ≫Easy multi language web interface
sources) - Soft patch ≫M10 insert for truss mounting - holes for wall mounting
≫DMX snapshot - Snapshot playback ≫ Supported protocols: Art-Net I II III, DMX 512, RDM (E1.20), sACN
≫Synced outputs (E1.31), RTTrP-L (BlackTrax)

ETHERNET DMX8 TRUSS MKII

The Ethernet-DMX8 / Truss MkII is the truss mounted version of the
Ethernet-DMX8 MkII. Fitted with a rugged enclosure, the unit o ers two
M10 inserts for easy truss mounted application, and a display for quick
con guration. This rock solid form factor makes the Ethernet-DMX8 /
Truss MkII the perfect tool for versatile productions and installations.

ETHERNET DMX8 MKII

The Ethernet - DMX8 MkII is the 8 ports edition of the Ethernet-
DMX converter range. The unit serves 8 shielded DMX outlets, that
can be used as input or output*. The unit o ers also two Ethernet
ports (front and rear) for an easy network connection, and a
graphical display for a better settings visualization. This unit is the
ideal companion for high demanding lighting show, where channel
count requires lots of DMX outputs.
Features
Features ≫4 x bi-directionnal DMX connector (Input / Output)
≫8 x bi-directionnal DMX connector (Input / Output) ≫2 x 10/100BaseTX Ethernet port
≫2 x 10/100BaseTX Ethernet port ≫Optic and galvanic isolated outputs.
≫Optic and galvanic isolated outputs. ≫Shielded connectors
≫Shielded connectors ≫Front end display for quick con guration
≫Front end display for quick con guration ≫The unit can be powered either through PoE (802.3af ) or mains
≫Easy multi language web interface (create a backup for your power source)
≫ Supported protocols: Art-Net I II III, DMX 512, RDM (E1.20), sACN ≫Easy multi language web interface
(E1.31), RTTrP-L (BlackTrax) ≫M10 insert for truss mounting - holes for wall mounting
≫Optional PoE support ≫Supported protocols: Art-Net I II III, DMX 512, RDM (E1.20), sACN
(E1.31), RTTrP-L (BlackTrax)
Functions
≫Converter (Ethernet<>DMX, Ethernet<>Ethernet) Functions
≫DMX Splitter, Ethernet & DMX merger ≫Converter (Ethernet<>DMX, Ethernet<>Ethernet)
≫RDM Gateway ≫DMX Splitter, Ethernet & DMX merger - RDM Gateway
≫ DMX trigger (remote selection of the control source, fade between ≫ DMX trigger (remote selection of the control source, fade between
sources) - Soft patch sources) - Soft patch
≫DMX snapshot - Snapshot playback ≫DMX snapshot - Snapshot playback
≫Synced outputs ≫Synced outputs
