03 LUMINEX

GROUPS
The Luminex GigaCore switches o er user to isolate devices from each other. As an example, user can isolate audio over IP data from light over IP
data. This avoids devices to be ooded by unrequested data, especially for broadcasted protocols such as ArtNet. This results in a better tra c
shaping, and network performances.
Through the very user friendly web interface, or through the front panel display (16Xt and RFO models only), the user can assign ports into speci c
groups.
The GigaCore switches o er up to 20 groups, each of them represented by a speci c colour. In this case, only ports assigned with the same colour
can communicate together (red talks to red, green talks to green, and so on).

GIGACORE 16RFO

The GigaCore 16RFO is a unit designed without compromises, speci
cally with touring application in mind and with the feedback of key
industry players. The units comes with all the advanced functionalities of
the GigaCore Ethernet switches range, in a fully touring oriented
package. The 2U high unit o ers rugged optical connectors options such
as OpticalCon, settable at the front or the rear of the unit, making a very
exible solution. Full backup on power supply is available, bringing true
redundancy at power level. Front end display, rugged connectors, and
GIGACORE 16XT the easiest managed switch interface available on the market, make this
product the ideal companion for a stressless tour !
The GigaCore 16Xt is a Gigabit Ethernet switch designed to cope
with the most demanding lighting and AV installations. Managed
through an intuitive web interface, the unit can also be con gured
from the front end display, making this switch an hassle-free
solution for every day job. Four SFP cages also o er users to
create complex network topologies over ber link, such as mesh
or ring. Additional available options makes the GigaCore 16Xt one
of the most secured system of the industry.
Features
≫Wire-speed Layer 2/3 managed switch
≫Industry speci c web interface
≫12 x Gigabit Ethercon port
≫4 x Gigabit compliant SFP cages Features
≫Front end display for basic con guration ≫Wire-speed Layer 2/3 managed switch
≫3 LEDs per port: PoE, RLinkX, Link/Speed ≫Industry speci c web interface ≫12 x Gigabit Ethercon port
≫4 status LEDs for the device: OK, PoE, RLinkX, Power ≫4 x Gigabit compliant SFP cages
≫Group : See description on page 24 ≫Front end display for basic con guration
≫RLinkX : See description on page 28 ≫Redundant fans ≫3 LEDs per port: PoE, RLinkX, Link/Speed
≫ Tailored for industry protocols, such as : AES67, ArtNet, ≫4 status LEDs for the device: OK, PoE, RLinkX, Power
DanteTM, Ethersound, MANet 1&2, Q-LAN, REACTM, sACN ≫ 4 slots at the front and the rear for D-Type connectors such as Neutrik
and many more... OpticalCon or Fiberfox
≫Pro le manager ≫IEEE 1588 PTP V2 ≫Group : See description on page 24
≫RLinkX : See description on page 28 ≫Redundant power supply
Options
≫ PoE supply unit: Deliver up to 150W through the 10 front Options
Ethercon connectors ≫ PoE supply with redundant supply to deliver up to 150W through the
≫Redundant Power and PoE Supply (See RPSU page 28) 10 front Ethercon connectors
