08 OPTIKENETICS

GoboPro LED

Following the success of the GoboPro and GoboShow
projectors, [OPTI] Kinetics presents their new replacement LED
Gobo Projectors. Launching in May 2016, [OPTI] Kinetics first
waterproof Gobo Projectors will be able to project static and
rotating images simultaneously or individually. There are three
models to choose from and supplementary accessories. These FEATURES
powerful gobo projectors can use any 52.5mm diameter object ≫ Projector Static and/or Rotating Image
lens, can be used for internal or external projectors and are perfect ≫Waterproof - IP 65 Rated
for Retail, Promotion, DJ, Clubs, Bars, Restaurants and Show ≫Cool and Virtually Silent
Room applications. Manufactured with long life LEDs , the ≫Bright Long Life LED
projectors have low power consumption and minimal heat emission. ≫Tamper Resistance

[OPTI] GoboPro LED Projector
Part Number FG2110 Colour temperature (Kelvin) 5500 K
Static and/or rotating image. Colour of Projector Black
Gobo Projection Integral Rotator for Cassette. 50mm o/d Rotating, 44mm o/d fixed. (42 image diameter). Or 35mm
Gobo Size
Projector takes 52.5mm diameter object lenses transparency with adaptor (for occasional use). Fitted to [OPTI] cassette
Lens Size
Other lenses available* Control Manual
Lens options 45, 60, 85, 120, 150 Protection Rating IP 65 with front cover fitted. Suitable for outdoor use.
Focus Manual Power Supply Mains adaptor 12V at 3.5A.
Light Source 30W LED Adaptors can be mounted integral to stand, or remote.
Lumens 1000 Dimension of projector L34 H25 W14 OD10 CM
Brightness 1270 Lux at 1m Diameter Weight 1.6Kg

Projection Distance

45mm (Lens) 60mm (Lens)

Ratio for Distance 1,1:1 (Image Size - 45mm Lens) Ratio for Distance 1,4:1 (Image Size - 60mm Lens)
The Object Diameter is 42mm The Object Diameter is 42mm
no other light sources nearby no other light sources nearby
very dark environment

85mm (Lens) 120mm (Lens)

Ratio for Distance 2:1 (Image Size - 85mm Lens) Ratio for Distance 2,9:1 (Image Size - 120mm Lens)
The Object Diameter is 42mm The Object Diameter is 42mm
