06 COEMAR

Canali Fashion Show - Milan Italy Canali Fashion Show - Milan Italy

Lite Led Series
Soft Lite Led RGBW

KEY FEATURES Soft Lite Led
≫ RGBW color mixing SPECIFICATIONS
≫LED so light, ideal for broadcast segment RGBW color mixing
≫White ranging from 2.700 K to 10.000 K with Electronic dimmer from 0% to 100%
color rendering index greater than 90 (CRI>90) Light project angle of 120°
≫Plus minus green regula on Electronic control of the cooling system
≫Color satura on channel Tempered frontal policarbonate (UV)
≫Indirect fully uniform illumina on Guaranteed Flicker-free opera on, LEDs frequency controlled via DMX
≫Smooth 16 bit dimmer from 600 Hz to 19000 Hz
≫ Flicker-free opera on with LEDs frequency controlled via DMX Fan setting with 3 different options (low, auto, DMX regulated)
from 600 Hz to 19000 Hz Aluminium extruded and steel body
≫250 W LED light source Double dissipa on system air forced heat pipe and fan
≫The fan setting allows three options : low, auto, DMX regulated PHYSICAL SIZE
≫Ultra quiet opera on: ideal for low noise applica ons Length 208.2 mm (8.2 in)
Height 602 mm (23.7 in)
Soft Lite Led Height with bracket 270.8 mm (10.6 in)
Side Vision Weight 9.6 Kg (21.1 lbs)
LIGHT SOURCE
96 Cree LEDs, 24 Red, 24 Green, 24 Blue, 24 White
CONTROL PROTOCOL AND PROGRAMMING
USITT DMX512/1990
Setting, addressing, testing and measurements via LEDs display
Soft Lite Led Rear Panel
RGBW Color Mixing ELECTRICAL SPECIFICATIONS/CONNECTIONS
90-240V, auto sensing, 50/60 Hz, 2 m (6.6 )
AC power PowerCon cable without power plug
In and Out PowerCon connectors to feed up to 10 (at 230 VAC) or 5 (90 VAC)
Power consumotion 1.2 A at 230 V, 2.43 A at 115V - cosφ 0,9
DMX data in/out XLR 3 M/F and 5 M/F

SoftLite Led - Accessories

Code Description Code Description Code Description Code Description
BC10026A001 Color frame holder BC10026A002 4 leaf barndoor BC10026A003 Honeycomb (6 mm) BC10026A004 Honeycomb (10 mm)
