- Specification
DMX/RDM FEATURES
| DMX zone selection | Yes (per output) |
| HTP/LTP merger | Yes |
| DMX backup mode | Yes |
| Regeneration mode | Yes |
| RDM discoverable | Yes |
| RDM filtering | Yes (per input and output) |
Extra features
| DMX port isolation | Optical and galvanic isolation per port |
| Short circuit protection | Yes |
| DMX port termination/biasing | Yes |
| Dark mode | Yes |
| User presets | 2 |
| Lockable front panel | Yes |
Connectivity
| DMX input | 2x gold plated Neutrik 5 pin XLR (male – front) / 2x gold plated Neutrik 5 pin XLR (male – rear/thru) |
| DMX output | 10x gold plated Neutrik 5 pin XLR (female) |
| POWER | 1 x Neutrik PowerCON TRUE1 in/out |
STATUS REPORT
| POWER | 1 x RGB LED on the front panel |
| DMX INPUT | 2 x RGB LED on the front panel |
| DMX OUTPUT | 10 x RGB LED on the front panel |
| LOCKABLE FRONT PANEL | Yes |
POWER
| POWER INPUT | AC 100-240V, 16A, 50-60Hz |
| POWER OUTPUT | MAX 15A |
| POWER CONSUMPTION | AC 100-240V, 0.2-0.1A, 50-60Hz |
PHYSICAL
| DIMENSION (WxDxH) | 482 x 204.85 x 44 mm |
| WEIGHT | 2.54kg |
ENVIRONMENTAL
| OPERATING TEMPERATURE | 0 to 50℃ |
| STORAGE TEMPERATURE | -10 to 70℃ |
