- Specification
Key features
| Merging engine | Yes |
| Softpatch | Yes |
| Trigger system | Yes |
| ReRoute | Yes |
| Profile manager | Yes |
| Snapshot | Yes |
| Monitoring software | LumiNet Monitor V2 (free) |
Ethernet/DMX features
| DMX port direction | Input or output (configurable) |
| DMX port isolation | Optical and galvanic isolation per port |
| DMX port termination/biasing | Yes |
| DMX timing | 10-40fps – break: 176-352µs |
| Ethernet port speed | 100Mbps |
| Port sensing | MDI / MDIX |
Connectivity
| DMX connectivity | 4x shielded & gold plated Neutrik 5 pin XLR (female) |
| Ethernet connectivity | 2x shielded Neutrik Ethercon connector |
| Rear connectivity | Not applicable |
POWER
| Power connectivity | 1x Neutrik powerCON inlet |
| Power input | 100-240VAC / 50-60Hz |
| Power consumption | Maximum 15W |
Protocols
| DMX protocols | DMX512 (1986 & 1990), DMX512-A, RDM ANSI E1.20 |
| Ethernet protocols | Art-Net™ (1-4), sACN ANSI E1.31, RTTrPL (BlackTraX) |
Configuration
| Display and jog | Yes |
| Configuration | Through the built-in web server or with the front end display menu |
| Status LEDs | Power LED, Ethernet Port LED (link and activity) |
Physical
| Dimensions (W x D x H) | 260 x 164 x 100 mm |
| Weight | 2.3 kg |
| Operating temperature | 0 tot +60°C |
| Storage temperature | -10 tot +70°C |
